The BOOST Products Thermal Insulation Heat Shield Pro Kit gives you stainless heat-shield material and a 39 x 39-inch ceramic fiber mat to build a custom barrier around exhaust, turbo, and engine-bay heat sources.
Kit Information
- For custom automotive or industrial thermal-protection projects
- Cut, form, and install around the specific component being protected
- Common uses include exhaust sections, manifold areas, turbocharger surroundings, and nearby heat-sensitive components
Fitment Note
This is a material kit for custom fabrication, not a vehicle-specific heat shield. Confirm available space, mounting method, material clearances, and the heat exposure of your project before ordering.
Specs and Features
-
Kit Details
- BOOST Products Thermal Insulation Heat Shield Pro Kit
- Manufacturer part number: EX-HI-TH-PRO
- Designed for custom thermal barriers and heat shielding
- Manufactured in the European Union
-
Stainless Heat-Shield Sheets
- Includes two sheets
- Material: 1.4828 stainless steel, AISI/SAE 309 equivalent
- Sheet size: 39 x 19.5 inches, 1000 x 500 mm each
- Sheet thickness: 0.004 inch, 0.1 mm
- Heat resistance: over 1,000°C, 1,800°F
-
Ceramic Fiber Insulation Mat
- Includes one ceramic fiber mat
- Mat size: 39 x 39 inches, 1000 x 1000 mm
- Mat thickness: 3/16 inch, 5 mm
- Self-adhesive backing for placement after trimming
Product Description
This Pro Kit is for fabricators and enthusiasts who need more than a small pre-cut shield. It gives you two thin AISI 309 stainless sheets for the outer heat barrier and a larger ceramic fiber mat for added insulation behind it. The material can be trimmed and shaped around the area you are trying to protect.
The stainless layers reflect and block radiant heat, while the ceramic fiber mat adds insulation between the heat source and the component behind the shield. It is a useful approach around exhaust tubing, manifolds, turbocharger areas, wiring, fluid lines, intake parts, and body panels when a vehicle-specific shield is not available.
Installation Notes
Plan the shield around the actual heat source and leave appropriate clearance for moving parts, hoses, wiring, and service access. BOOST Products recommends trimming the ceramic mat, placing it around the component, forming the stainless sheet around it, and welding the shield assembly where appropriate. The final temperature reduction depends on source temperature, exposure time, airflow, and the finished shield design.
Related Heat-Control Upgrades
- PTP T3/T4 turbo blanket - A direct heat-control option for common T3 and T4 turbocharger housings.
- PTP Lava T3/T4 turbo blanket - A higher-temperature blanket option for a turbo build that also uses custom heat shielding.
- ISR titanium turbo blanket for T25/T28 turbos - A compact blanket option for smaller turbocharger applications.
About BOOST Products
BOOST Products develops motorsport-focused plumbing, fabrication, heat-management, and performance components. Its thermal-protection materials are made for builders who need to control heat around custom engine, turbo, and exhaust systems.
