The ASE V2 twin fuel pump hanger lets you run one or two pumps in an IS300 or Altezza fuel tank, with E85-compatible anodizing, high-amperage connections, and staged-pump capability for a serious fuel-system build.
Fitment Information
-
Lexus IS300 XE10
- IS300 (2001, 2002, 2003, 2004, 2005)
-
Toyota Altezza XE10
- Altezza (1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005)
Fitment Note
This hanger fits the Lexus IS300 and Toyota Altezza fuel tank. The Lexus GS300 and Toyota Aristo use a different ASE hanger and are not compatible with this kit.
Options
-
Kit Configuration
- Hanger only
- Hanger with AN fittings
- Hanger with banjo fitting
-
Relay Kit
- No relay kit
- Add relay kit
Specs and Features
- AutoSports Engineering V2 twin fuel pump hanger
- Fits major aftermarket fuel pumps
- Run one or two pumps; plug supplied for a single-pump setup
- Stud-style electrical connectors for high-amperage pumps
- Ring terminals included
- Integrated venturi pump in the pump bracket
- 6AN return provision
- Single 6AN or 8AN outlet, depending on selected configuration
- Anodized for E85 compatibility
- 8AN feed and 6AN return configuration tested above 1,200 horsepower
Product Description
The ASE V2 twin fuel pump hanger is for IS300 and Altezza owners building beyond the limits of a single factory-style pump arrangement. It replaces the in-tank hanger with a setup that can support one pump for a simpler build or two pumps for a higher-output gasoline or E85 fuel system.
The hanger uses stud connectors for the electrical load of high-amperage pumps, an integrated venturi pump bracket, and AN or banjo connection options to suit the rest of the plumbing. The 8AN feed and 6AN return configuration has been tested above 1,200 horsepower, making this a real foundation part for a turbocharged 2JZ-GE or engine-swapped IS300 build.
Staged Twin-Pump Setup
ASE recommends staging the pumps instead of operating both full time. The car can start, idle, and cruise on one pump, with the second activated only when fuel demand requires it. This helps reduce fuel temperature and unnecessary pump wear during normal driving.
Before You Buy
Choose the fitting option that matches your fuel lines and confirm the pumps, wiring, fuel-pressure regulator, injectors, and ECU strategy are sized as one system. The optional relay harness is not vehicle-specific and uses standard four-pin relay wiring. The supplied dust seals are for the external connector only; do not install them inside the fuel tank.
Related Fuel System Upgrades for Your IS300
- Walbro 450 LPH E85 high-pressure in-tank fuel pump - A high-flow, E85-compatible pump option for the ASE hanger’s one- or two-pump setup.
- AEM 50-1200 340 LPH E85-compatible in-tank fuel pump - A compatible high-flow pump option for IS300 owners building the fuel system around E85 capability.
About AutoSports Engineering
AutoSports Engineering develops fuel-system, drivetrain, and conversion components for import performance builds. Its products are designed around practical installation, high-output power combinations, and the component choices common in serious street and race projects.
