Lower Your 5th Gen Outback Without Giving Up Adjustability
BC Racing BR Series coilovers give the 2015-2019 Subaru Outback adjustable ride height and 30-way damping control in a complete four-corner suspension kit. The F-29 kit is built for BS9 AWD models and is a good fit for owners who want a lower stance with more control over how the Outback feels on the road.
Fitment Information
- Subaru Outback 5th Gen BS9 AWD (2015, 2016, 2017, 2018, 2019)
Fitment Note
This kit is designed for AWD Outback models. BC Racing lists a typical lowering range of about 1 to 2 inches. It is a lowering coilover kit, not a lift kit, and factory ride height cannot be achieved on most applications.
Specs and Features
-
BC Racing BR Series Coilovers
- Manufacturer part number: F-29
- Complete set of four coilovers
- Mono-tube damper design with linear piston and damping curve
- Fully rebuildable design
-
Adjustment
- 30-way simultaneous compression and rebound damping adjustment
- Ride-height adjustment independent of spring preload
- Typical 1 to 2-inch lowering range
-
Springs and Mounts
- Front spring rate: 6 kg/mm
- Rear spring rate: 5.5 kg/mm
- Front camber plates included
- Rear camber plates are not applicable for this kit
-
Warranty
- One-year BC Racing warranty against manufacturer defects when purchased through an authorized dealer such as Redline360
Product Description
The BC Racing F-29 BR Series coilovers replace the factory struts and springs on the 2015-2019 Subaru Outback with a height-adjustable, mono-tube setup. Ride height is adjusted at the shock body instead of by compressing the spring, so you can set the stance you want without sacrificing spring preload just to lower the vehicle.
Damping is adjusted through a single 30-way knob that changes compression and rebound together. Start near the middle, drive the car, then make small adjustments from there. Softer settings work better for rougher streets, while firmer settings can help reduce body movement on smoother roads and through corners.
Setting Up Coilovers on Your 5th Gen Outback
It is best to set the final ride height with your wheels and tires installed, then get an alignment once the suspension has settled. Lowering an Outback can change rear camber and toe, so adjustable rear arms and end links can make it easier to get the alignment and sway bar position where you want them.
Related Suspension Upgrades for Your Outback
- Godspeed Rear Lower Camber Control Arms - Add rear camber adjustment after lowering your 2015-2019 Outback.
- Eibach Adjustable Rear Sway Bar End Links - Help correct rear sway bar geometry on a lowered Outback.
- Megan Racing 25.4mm Front Sway Bar - A larger front bar to complement the more controlled feel of a coilover setup.
About BC Racing
BC Racing builds vehicle-specific coilover suspension systems for street-driven, track-driven, and project vehicles. Its BR Series combines adjustable ride height, 30-way damping, rebuildable mono-tube dampers, and application-specific spring rates in a practical all-in-one suspension package.
